DN15 DN600 Size Flanged Globe Valve With Stainless Steel Stem High Pressure

DN15 DN600 Size Flanged Globe Valve With Stainless Steel Stem High Pressure

  • DN15 DN600 Size Flanged Globe Valve With Stainless Steel Stem High Pressure
DN15 DN600 Size Flanged Globe Valve With Stainless Steel Stem High Pressure
Dettagli:
Luogo di origine: porcellana
Marca: TOBO
Certificazione: API ISO CE
Numero di modello: SS316
Termini di pagamento e spedizione:
Quantità di ordine minimo: 5pcs
Prezzo: Negotiation
Imballaggi particolari: Cartone, caso Piega-di legno o secondo la richiesta dei clienti
Tempi di consegna: 10 giorni lavorativi
Termini di pagamento: L/C, T/T, Western Union
Capacità di alimentazione: 1000pcs al mese
Contatto
Descrizione di prodotto dettagliata
Nome di produzione: Valvola di globo flangiata Materiale: SS316
Estremità: Estremità flangiata Applicazione: Gas, petrolio, acqua, liquido di Corrosie e vapore
Dimensione: DN100 Pressione: 150#-600#
Tempreture: Temperatura elevata Posizione del filo del gambo: Valvola di globo esterna del gambo della vite
Evidenziare:

DN15 Flanged Globe Valve

,

Stainless Steel Stem Flanged Globe Valve

,

ANSI 16.5B Flanged Globe Valve

SS316 Flanged Globe Valve With Flange End 150 Class , Material Class 316

Key Features:

  • Detailed Product Description
    Product Name: Flanged Globe Valve Application: Acid, Water, Sewage Etc.,
    Size: DN15 ~DN600 Pressure: PN16 /125lbs /JIS 5K
    Standard: API 6D/ ANSI 16.5 B/ JIS 20K/JIS 10K Temperature: -29~425 C
    Body: Cast Iron / Grey Iron / Ductile Iron Stem: Stainless Steel/ 2Cr13
    High Light:

    cast steel globe valve

    ,

    2 inch globe valve





    DN15 ~DN600 Size Flanged Globe Valve With Stainless Steel Stem High Pressure



    Diaphragm valve , body butyl rubber vulcanized/lined and butyl rubber diaphragm



    Specification
    design length flanged test mark
    GB/T 12239 GB/T 12221/JB1688 JB/T78, GB4216 GB/T 13927 GB/T 12220





    Material
    No. name   cast iron steel stainless steel
    1 Body/Bonnet   HT250 WCB CF8 CF8M CF3 CF3M
    2 Disc/Stem   HT250 1Cr13 1Cr18Ni9Ti 1Cr18Ni12Mo2Ti 00Cr18Ni10 00Cr17Ni14Mo2
    3 Trim/seat   (Natural rubber),(Isobutylene-isoprene rubber),PTFE(F4),FEP(F46)
    4 Diaphragm   Rubber, fluoro plastic
    5 hand wheel   HT250







    PN

    work

    pressure

    DN L D D1 N-φd F H1 H2 D0 weight
        mm inch
    1.0 1.0 15 1/2" 125 95 65 4-14 2 105 116 100 4.5
    20 3/4" 135 105 75 4-14 2 117 128 100 4.5
    25 1" 145 115 85 4-14 2 121 135 120 5
    32 1-1/4" 160 140 100 4-18 2 132 150 120 7
    40 1-1/2" 180 150 110 4-18 3 156 176 140 9
    50 2" 210 165 125 4-18 3 169 195 140 14
    65 2-1/2" 250 185 145 4-18 3 200 236 200 19
    80 3" 300 200 160 4-18 3 216 256 200 29
    100 4" 350 220 180 8-18 3 270 322 280 45
    125 5" 400 250 210 8-18 3 338 406 320 62
    150 6" 460 285 240 8-22 3 384 464 320 80.5
    0.6 0.4 200 8" 570 340 295 8-22 4 518 638 400 146
    250 10" 680 395 350 12-22 4 598 734 500 240
    300 12" 790 445 400 12-22 4 698 778 500 334
    350 14" 900 505 460 16-22 4 723 883 500 371
    0.25 400 16" 1000 565 515 16-25 4 868 1078 640 584



    DN15 ~DN600 Size Flanged Globe Valve With Stainless Steel Stem High Pressure 0

    DN15 ~DN600 Size Flanged Globe Valve With Stainless Steel Stem High Pressure 1







      L D D1 D2 f b Z-φd D D1 D2 f b Z-φd

    DN

    (mm)

    NPS

    (inch)

    PN1.0MPa PN1.6MPa
    15 1/2" 125 80 55 40 2 12 4-φ12 95 65 45 2 14 4-φ14
    20 3/4: 135 90 65 50 2 14 4-φ12 105 75 55 2 16 4-φ14
    25 1" 145 100 75 60 2 14 4-φ12 115 85 65 2 16 4-φ14
    32 1-1/4" 160 120 90 70 2 16 4-φ14 135 100 78 2 18 4-φ18
    40 1-1/2" 180 130 100 80 3 16 4-φ14 145 110 85 3 18 4-φ18
    50 2" 210 140 110 90 3 16 4-φ14 160 125 100 3 20 4-φ18
    65 2-1/2" 250 160 130 110 3 16 4-φ14 180 145 120 3 20 4-φ18
    80 3 300 185 150 125 3 18 4-φ18 195 160 135 3 22 4-φ18
    100 4 350 205 170 145 3 18 4-φ18 215 180 155 3 22 8-φ18
    125 5 400 235 200 175 3 20 8-φ18 245 210 185 3 24 8-φ18
    150 6 460 260 225 200 3 20 8-φ18 280 240 210 3 24 8-φ23
    200 8 570 315 280 255 3 22 8-φ18 335 295 265 3 26 8-φ23
    250 10 680 370 335 310 3 24 12-φ28 390 350 320 3 28 12-φ23
    300 12 790 435 395 362 4 24 12-φ23 440 400 368 4 28 12-φ23




    The globe valve is designed reference to advanced internal and international standard.Adopting different material, the valve may works with different medium, such as water,oil,gas,steam,carbamide and other medium.







    selection of possible applications:
    (industry) (power station)
    (flue gas puerification plant) (gas supply)
    (vacuum facilities) (ammonia)
    (hot water) (cllling&freezing systme)
    (heating technology) (steam system)






    Notes:The size of serial,valve connecting flange can be design according to customers reguirment.

    Products performance specification



    Parts Materials
    Body ASTM A216 GR.WCB
    Seat Ring ASTM A105 + Stellite Faced
    Disc ASTM A105 + 13Cr Faced
    Disc Thrust Plate ASTM A276 Type 420
    Disc Nut ASTM A276 Type 410
    Stem ASTM A182 GR.F6
    Bonnet Bolt Nuts ASTM A194 GR.2H
    Bonnet Bolts ASTM A193 GR.B7
    Gasket Soft Iron + Graphite
    Backseat Bushing ASTM A276 Type 410
    Stem Packing Braided Graphite & Die formed Graphite Ring
    Bonnet ASTM A216 GR.WCB
    Eyebolt Pins Carbon Steel
    Gland ASTM A276 Type 410
    Gland Flange ASTM A216 GR.WCB
    Gland Eye Bolts ASTM A307 GR.B
    Eyebolt Nuts ASTM A194 GR.2H
    Yoke Bush ASTM A439 GR.D-2
    Screw Carbon Steel
    Hand Wheel Ductile Iron
    Hand Wheel Nut ASTM A194 GR.2H
    Washer Carbon Steel
    Yoke ASTM A216 GR.WCB
    Yoke Pan Bolt Nuts ASTM A194 GR.2H
    Yoke Pan Bolt ASTM A193 GR.B7
    Bearing Steel
    Lantern Ring On Request ASTM A276 Type 410

    SS316 Flanged Globe Valve With Flange End 150 Class , Material Class 316 3 SS316 Flanged Globe Valve With Flange End 150 Class , Material Class 316 4 SS316 Flanged Globe Valve With Flange End 150 Class , Material Class 316 5



    Main Dimensions



    ASME Pressure Class 150 Lb-Dimensions and Weights


    NPS in 2 2.5 3 4 5 6 8 10 12 14 16
    d mm 51 64 76 102 127 152 203 254 305 337 387
    L-L1 in 8 8.5 9.5 11.5 14 16 19.5 24.5 27.5 31 36
    (RF-BW) mm 203 216 241 292 356 406 495 622 698 787 914
    L2 in 8.5 9 10 12 14.5 16.5 20 25 28 31.5 36.5
    (RTJ) mm 216 229 254 305 368 419 508 635 711 800 927
    H in 13.43 14.45 14.76 19.02 21.14 20.35 23.23 29.69 37.05 42.72 38.03
    (open) mm 341 367 375 483 537 517 590 754 941 1085 966
    W in 7.87 9.84 9.84 11.81 11.81 13.78 15.75 17.72 25.2 25.2 18.11
    mm 200 250 250 300 300 350 400 450 640 640 460
    WT BF 22 29 42 64 77 105 154 288 507 617 810
    (Kg) BW 19 25 34 49 65 82 131 249 430 580 763



    ASME Pressure Class 300 Lb-Dimensions and Weights

    NPS in 2 2.5 3 4 5 6 8 10 12
    d mm 51 64 76 102 127 152 203 254 305
    L-L1 in 10.5 11.5 12.5 14 15.75 17.5 22 24.5 28
    (RF-BW) mm 267 292 318 356 400 444 559 622 711
    L2 in 11.12 12.12 13.12 14.62 16.37 18.12 22.62 25.12 28.62
    (RTJ) mm 283 308 333 371 416 460 575 638 727
    H in 13.74 14.8 16.93 19.13 22.05 24.33 36.89 37.36 39.17
    (open) mm 349 376 430 486 560 618 937 949 995
    W in 7.87 9.84 9.84 13.78 15.75 17.72 2.05 25.2 18.11
    mm 200 250 250 350 400 450 560 640 460
    WT BF 31 43 57 86 130 168 280 385 724
    (Kg) BW 26 38 44 68 110 138 228 329 618



    ASME Pressure Class 300 Lb-Dimensions and Weights



    NPS in 2 2.5 3 4 6 8 10 12
    d mm 51 64 76 102 152 200 248 298
    L-L1 in 11.5 13 14 17 22 26 31 33
    (RF-BW) mm 292 330 356 432 559 660 787 838
    L2 in 11.62 13.12 14.12 17.12 22.12 26.12 31.12 33.12
    (RTJ) mm 295 333 359 435 562 664 791 841
    H in 16.73 19.76 20.51 24.41 34.88 36.69 40.94 50.39
    (open) mm 425 502 521 620 886 932 1040 1280
    W in 9.84 11.81 13.78 17.72 22.05 18.11 24.02 29.92
    mm 250 300 350 450 560 460 610 760
    WT BF 39 58 73 120 327 482 700 900
    (Kg) BW 33 48 61 95 261 385 588 795







    SS316 Flanged Globe Valve With Flange End 150 Class , Material Class 316 6









    Brief introduction:

    The globe valve is designed reference to advanced internal and international standard. The body adopt

    sphere configuration, and it also has the feature of good appearance, nice function and superior quality.



    Apply from CLASS150 to CLASS1500, and -29℃~425℃(steel), -40℃~550℃(stainless steel).



    Using different material, the valve may works with different medium, such as water,oil,gas,steam,carbamide and

    other medium.



    Features:

    - Back seal

    Back seal design to ensure dependable packing and sealing when valve is fully opened.(Replacement of packing under pressure is not recommended)



    - Resist friction

    Valve disc is given enough intensity and rigidity. Disc sealing surface may be built-up welded with satellite alloy

    inlaid or other material responding to the users’ requests .



    - Precise design:

    Design the body and bonnet according to precise calculation. Body and bonnet have high strength ,

    rigid and flow ability .



    Mail part & material

      Item Name of parts material
    1 Body WCB, CF8, CF8M
    2 Seat 2Cr13,25+ satellite
    3 Disc 2Cr13, 304, 25+satelite
    4 Stem 2Cr13, 304, 304L
    5 Gasket Graphite+304, Graphite+08 steel
    6 Bonnet WCB,CF8,CF8M
    7 Packing Graphite,PTFE
    8 Hand wheel HT250,QT450







    Technical Specification

    -Nominal diameter: 2”-12”

    -Applicable Temperature: -29℃~425℃(steel) -40℃~550℃

    (stainless steel)

    -Nominal pressure: 150Lb 300Lb 600Lb 900Lb 1500Lb

    -Applicable Medium: water ,gas,oil,and other causticity medium.

    Applications Standard

    -Manufacture standard : ANSI B16.34

    -Face to face dimension: ANSI B 16.10

    -Flange dimension: ANSI B 16.5

    -Test: API 598







    Description:



    Main external and connection dimension



    SS316 Flanged Globe Valve With Flange End 150 Class , Material Class 316 7

      CLASS150
    size(in) 2" 2-1/2" 3" 4" 5" 6" 8" 10" 12"
    L,L1-RF.BW(mm) 203 216 214 292 330 356 495 622 698
    L2-RTJ(mm) 216 229 254 305 343 368 508 635 711
    H(mm) 330 390 410 475 540 585 725 825 940
    K(mm) 200 250 250 300 350 350 450 500 600
    Weight(Kg) 23 29 40 59 95 115 178 268 385



      CLASS300
    size(in) 2" 2-1/2" 3" 4" 5" 6" 8" 10" 12"
    L,L1-RF.BW(mm) 267 292 318 355 400 440 533 622 711
    L2-RTJ(mm) 283 308 333 371 416 460 549 638 727
    H(mm) 350 425 485 520 565 655 825 920 1155
    K(mm) 200 250 300 300 350 350 500 600 700
    Weight(Kg) 30 45 60 83 135 162 265 375 525



      CLASS600
    size(in) 2" 2-1/2" 3" 4" 5" 6" 8" 10"
    L,L1-RF.BW(mm) 292 330 356 432 508 559 660 787
    L2-RTJ(mm) 295 333 359 435 511 562 664 791
    H(mm) 420 490 550 590 620 700 950 1140
    K(mm) 250 300 300 350 500 500 600 600
    Weight(Kg) 39 61 76 122 210 245 447 692
      CLASS900
    size(in) 2" 2-1/2" 3" 4" 5" 6" 8"
    L,L1-RF.BW(mm) 368 419 381 457 559 610 737
    L2-RTJ(mm) 371 422 384 460 562 613 740
    H(mm) 495 540 600 655 670 780 1050
    K(mm) 300 350 350 500 500 350* 350*
    Weight(Kg) 96 79 117 178 305 355 730
    Note: Use "*", mean have fixed the gear box.



      CLASS1500
    size(in) 2" 2-1/2" 3" 4" 6"
    L,L1-RF.BW(mm) 368 419 470 546 705
    L2-RTJ(mm) 371 422 473 549 711
    H(mm) 550 582 625 750 925
    K(mm) 300 350 400 450 600
    Weight(Kg) 116 125 145 210

    475





Packing Details:



We choose suitable wood cases according to different valves and arrange skilled workers to pack in case of bruise. Long term cooperated forwarder will book space, clear customs and transport for us without delay. There are three ways for transportation, by sea, by air and by train. We will arrange transportation according to customers' needs.


Delivery Details: According to the order, 7~60days
